Electrolux Pro Electrolux gas fryer - 30 liters

Gas-heated fryer with two baskets measuring 240x380x505 mm, 13 - 15 liters, floor model with swing doors for the oil drain valves. The burners are mounted on the outside of the frying basket, creating a smooth basket with rounded corners that is very easy to clean. The external burners extend the lifespan of the oil. Laser technology enables a seamless connection with other units of the 900XP line.

Self-supporting stainless steel construction, extra reinforced. The rear and side walls are folded from a single sheet of stainless steel. 2 mm thick stainless steel worktop with flat top edges, with frying baskets made of 1.5 mm thick stainless steel. Ventilation opening with removable stainless steel grate. The metal control knobs are recessed on the front. Seamlessly welded V-shaped frying baskets with rounded corners, deep cold zone, and generously sized overflow zone.

The frying tank is pressed in two parts (the cold zone and the actual frying tank), which are seamlessly welded together by a robot, making leakage impossible. The stainless steel burners are invisibly positioned beneath the bottom of the frying tank and are equipped with a pilot flame, piezo ignition, and flame safety device. Stepless thermostatic temperature control from 120 - 190°C, with overheating protection. Includes two frying baskets 225x325x125 mm with cool-touch handles, two crumb grids, two stainless steel lids, and two oil collection trays. The base unit features a cabinet with double-walled swing doors and 1” drain valves. The unit has smooth surfaces for easy cleaning. Mounted on 4 stainless steel adjustable feet. IPX5 waterproof.

Description

• Deep-drawn V-shaped deep fryers.
• High-efficiency stainless steel 28 kW burners with flame safety device, mounted against the outside of the casing.
• Thermostatic control of the oil temperature up to a maximum of 190 °C.
• Flame safety device on every burner.
• An overheating protection thermostat is standard on all units.
• Oil drain valve under the tank with a collection tray in the base.
• All important components are placed at the front for easy servicing.
• Piezo ignition for extra safety.
• IPX5 waterproof certification.
• The special design of the control buttons prevents water infiltration.
• Mounted on four stainless steel adjustable feet. Stainless steel front, back, and side plinths are optionally available.
• Standard equipped with 2 baskets and a left and right-opening door in the base.
• The inside of the bin features rounded corners for easier cleaning.
• The 930 mm deep top provides a larger working surface.
• All exterior plating is made of stainless steel with a Scotch Brite finish.
• Right-angled sides ensure a flush connection with other units and prevent gaps and potential dirt accumulation between the devices.

General information

• Effective bin dimensions, length 240 mm
• Effective bin dimensions, height 505 mm
• Effective bin dimensions, width 380 mm
• Container capacity 13 lt MIN; 15 lt MAX
• Thermostat setting 120 °C MIN; 190 °C MAX

If the fryer is placed against or next to a temperature-sensitive appliance, a safety gap of approximately 150 mm must be provided between them, or heat insulation must be installed.
